SEN-QCQD Strong Magnetic Power Taking Device

Name: SEN-QCQD Strong Magnetic Power Taking Device
Availability: InStock

The high-intensity magnetic power taking device is mainly composed of high-intensity magnetic, copper rivets, high-temperature crimping terminal and high-temperature cable. When the cable needs to be powered, the high -intensity magnetic is mutually attracted to the screw below the switch or screw above the switch. After determining the branch position of the main line, it can contact with conductor. The product has small volume, convenient construction, can be built-in temperature sensor, performance parameters can be customized.

Inquiry Now

Product Features

It is easy to install, low cost, safe and reliable, maintenance free.

It can be used for live working and branch at any position of the cable.

The comprehensive benefits is obvious, and the cost performance is better than the traditional connection method.

Scope of Application

Electrical fire monitoring system, fire equipment power supply monitoring system, intelligent power system, small current grounding system, relay protection, motor protection system.

Performance Index

Electrical Parameters		Mechanical Parameters
Work Frequency	50~3000HZ	Shell	PC/PA Flame Retardant 94-V0
Rated Input	0-380V	Installation Mode	Magnetic Type
Rated Output	0-380V	Work Temperature	-12°C ~ +70°C
Output Mode	Cable	Connection Mode	Single Sheath Wire
Operation Measurement	Puncture (Temperature)	Temperature NTC	10K/50K/100K

Rural Power Grid Transformation, energy efficiency monitoring, smart power system.
